Gas filled
Gas filled
Gas filled
Gas filled
Gas filled
Gas filled

Gas filled

10L seamless steel cylinder specification

Water capacity

10L

gas capacity

1.5m³

Outer diameter

140mm

Working pressure

150bar

Test pressure

250bar

Weight

14.5kgs

Height

940mm

Standard

ISO9809-3

Color

As different gas color required

Material

37Mn

Valve

QF-2/CGA540/CGA580 etc

Accessories

Regulator, trolley.


· State-of-the-art manufacturing facilitates located on the East of China

· All Medical Oxygen cylinders are produced from high quality China sourced raw materials

· On-site ISO Inspections – dimensional, visual, hydrostatic, tensile & burst testing

· Serialization – complete traceability of cylinder production batch, test reports and raw material

· Personalized customer support – technical inquiries, new product development, logistics

· Customizable colors, labels and graphics

· All seamless steel cylinder design use life is 10 years.



We can provide the steel cylinder size from 2L to 80L, all the steel cylinder can be used for oxygen gas, also co2 gas, helium gas, nitrogen gas, argon gas , mix gas etc.



We can provide filling gas services, including N2, Co2, Ar, He, O2, C2H4 etc.

We will provide different gas MSDS document to help arrange shipment work.



Our steel cylinder produced according to ISO9809 or DOT3AA or EN ISO9809 standards, it depends on which country will the steel gas cylinder used in.

Our cylinder with TPED approved with pi mark which exporting to European country only.



ISO9809 standard 150BAR working pressure steel cylinder specifications

Serial No.

Type

working Pressure(bar)

Test pressure (bar)

Volume(L)

Outer Dia.(mm)

Length(mm)

Weight (kg)

1

BENE108-2-15

150

250

2

108

315

4

2

BENE108-3-15

150

250

3

108

480

5.7

3

BENE140-4-15

150

250

4

140

365

6.6

4

BENE108-5-15

150

250

5

108

700

7.5

5

BENE140-5-15

150

250

5

140

440

7.7

6

BENE140-6.3-15

150

250

6.3

140

540

9.4

7

BENE140-7-15

150

250

7

140

600

10.8

8

BENE140-8-15

150

250

8

140

685

11.0

9

BENE140-9-15

150

250

9

140

745

11.5

10

BENE140-10-15

150

250

10

140

825

13.4

11

BENE159-8-15

150

250

8

159

545

11

12

BENE159-10-15

150

250

10

159

675

13

13

BENE159-13.4-15

150

250

13.4

159

890

21

14

BENE180-20-15

150

250

20

180

985

25

15

BENE219-20-15

150

250

20

219

730

27

16

BENE219-40-15

150

250

40

219

1310

48

17

BENE232-50-15

150

250

50

232

1480

60

18

BENE267-68-15

150

250

68

267

1500

74

19

BENE279-80-15

150

250

80

279

1735

91

 We also provide the steel cylinder in 200bar and 300bar working pressure cylinders,



Welcome contact to communicate more information !
